Wearable Explosion Proof Phosphine Gas Monitor with 2-Year Standby Battery PH3 Gas Detector

Wearable Phosphine PH3 Gas Monitor Explosion Proof 2-Year Standby Battery

MiniMeta phosphine gas detector uses electrochemical sensor with four optional ranges (0-5/20/50/100ppm). IP68 dust/waterproof and Ex ia IIC T4 Ga explosion-proof certified. It runs 2 years on replaceable 3.6V dry battery, with triple alarm, power-on self-test and optional docking station for calibration, ideal for grain storage, semiconductor and chemical site personal protection.

MiniMeta is IECEx, ATEX and EMC certified single gas monitor customized for PH3 detection. Equipped with stable electrochemical sensor and selectable measuring ranges to fit various industrial standards. Adopting low-power design, it delivers up to 2 years standby without frequent charging or calibration. IP68 sealed housing adapts to humid, dusty and corrosive working conditions. It supports auto self-check, multi-level concentration alarms, and optional data logging. Matching single/multi-unit docking station enables batch bump test and data export. Compact 125g body with back clip allows all-shift wearable use.

• Electrochemical PH3 sensor with four optional ranges, accuracy ≤±2~5%FS and 15-30s T90 response to capture trace phosphine leakage precisely
• IP68 fully sealed casing, stable operation at -20℃~55℃ and 0-95%RH non-condensing environment against splashes and industrial dust
• Replaceable 3.6V dry battery for 2-year ultra-long standby, greatly reducing regular maintenance workload
• 95dB buzzer, dual red LED and vibration triple alarm, with adjustable high/low thresholds and TWA/STEL/low battery reminders
• Automatic power-on self-test, LCD displays real-time reading, TWA, STEL, MAX, MIN and remaining battery intuitively
• Modular sensor and battery for easy replacement; optional data logging and docking station for unified calibration & record export
• Mini size and 125g weight with back clip, lightweight for long-time wearing

• Grain & Tobacco Fumigation Storage PH3 is widely used as grain insecticide. The detector monitors residual gas to prevent poisoning during warehouse access and grain handling.
• Semiconductor & LED Manufacturing High-purity PH3 serves as chip doping source; the monitor tracks pipeline leakage to eliminate toxic and explosion hazards.
• Chemical Phosphorus Production Phosphide workshops generate PH3 by-products, providing continuous personal safety protection for frontline workers.
• Environmental & Waste Chemical Inspection Used by inspection teams to detect abnormal phosphine emissions from waste treatment facilities.
• Metal Plating Workshops Detect trace PH3 produced during electroless nickel plating to avoid long-term inhalation damage.
• Confined Space Pre-detection Gas inspection for phosphorus waste tanks and underground pipelines before personnel entry.

Q1: What gas is this detector designed for?

A: This customized model detects phosphine (PH3); sensors for hundreds of other toxic gases are optional.

Q2: What PH3 measuring ranges can I choose?

A: Four options: 0-5ppm, 0-20ppm, 0-50ppm, 0-100ppm.

Q3: Does the device need regular charging?

A: No. It uses replaceable 3.6V dry battery with a 2-year standby cycle.

Q4: What safety certifications does it hold?

A: IP68 protection, Ex ia IIC T4 Ga explosion-proof grade, certified by IECEx, ATEX and EMC.

Q5: Are sensor and battery replaceable? Any supporting calibration tool?

A: Both sensor and battery can be replaced separately. Optional docking station supports bump test and data export.

Q6: What alarm methods does it adopt?

A: Combined 95dB buzzer, dual red LED and vibration alarms with adjustable concentration thresholds.
